Plaincarboncoldrolledcoils,Plaincarbonhotrolledcoils,Galvanizedsteelcoils,Color-coatingsteelcoils,Stainesssteelcoils
Product Parameter Table
Model： | DYZJ0.1-1*500 | DYZJ0.2-2*800 | DYZJ0.3-3*1600 | DYZJ0.4-4*2000 | DYZJ0.5-5*2000 |
Coil material： | Plain carbon cold rolled coils, Plain carbon hot rolled coils, Galvanized steel coils, Color-coating steel coils, Stainess steel coils | ||||
Coil thickness： | 0.1-1mm | 0.2-2mm | 0.3-3mm | 0.4-4mm | 0.5-5mm |
Coil width： | 100-500mm | 100-800mm | 200-1600mm | 300-2000mm | 300-2000mm |
Coil weight： | ≤5000KG | ≤10000KG | ≤25000KG | ≤30000KG | ≤30000KG |
Coil i.d.： | Φ300，φ400，φ508 | Φ508，φ610 | Φ508，φ610 | Φ508，φ610 | Φ508，φ610，φ760 |
Coil o.d.： | ≤1600mm | ≤1800mm | ≤2000mm | ≤2100mm | ≤2200mm |
Strip width： | ≥10mm | ≥18mm | ≥30mm | ≥40mm | ≥50mm |
Number of strip： | 10-30 | 10-30 | 10-30 | 10-30 | 10-30 |
Slitting Accuracy： | +0.05mm | +0.1mm | +0.1mm | +0.15mm | +0.2mm |
Line Speed： | 0-200m/min | 0-200m/min | 0-180m/min | 0-160m/min | 0-120m/min |
Control System: | PLC Touch Screen | PLC Touch Screen | PLC Touch Screen | PLC Touch Screen | PLC Touch Screen |
